Combined antenna, WiFi, 2/5/6G
The Model ANT-HCB4-W14 Antenna features provides a high performance, external antenna solution. The antenna supports IEEE 802.11a/b/g/n/ac/ax/6e/be wireless standards and is intended for access points. The solution is suitable for low-cost, high-performance antenna applications.
AOT PN: ANT-HCB4-W14
| Frequency |
WiFi (2.4 GHz, 5GHz,6GHz) |
|---|---|
| Applications |
AOE (Enterprise) |
Features Overview
-
- Covering 2400-2484MHz/5150-5350MHz/5470-5730MHz/5955-6415MHz frequency
- Off-board, Cable-fed,
- Low Cost, High performance
- RoHS compliant.
Wireless Standard |
IEEE 802.11 a/b/g/n/ac/ax, WiFi 6E/WiFi 7 |
| Frequency Bands | 2400 -2490MHz/5150-5850MHz/5925MHz-7125MHz |
| Peak Realized Gain | 5.6dBi@2.4GHz/6.5dBi@5GHz/7.9dBi@6GHz |
| Realized Efficiency | >64%@2.4GHz/>59%@5GHz/>60%@6GHz |
| VSWR | <1.8@2.4GHz/<1.9@5GHz/<1.9@6GHz |
| Polarization | Linear Polarization |
| Radiation Pattern | Omni-directional |
| Feed Impedance | 50Ω |
| Power Handling | 30dBm |
| Antenna Structure | PCB Antenna/Stamped Metal Antenna |
| Feeding Description | Cable Feeding |
| Antenna Dimensions | 203.0 x 203.0 x 13.3(mm) |
| Weight | 95.5 g |
| Temperature Range | Operating temperature: -40° C to +75° C (-40° F to +167° F)
Storage temperature: -40° C to +85° C (-40° F to +185° F) |
